Jiangyin Huadong Machinery Co., Ltd. Home / Product / Belt Conveyor Pulley / Conveyor Slag Discharge Pulley

Conveyor Slag Discharge Pulley

The drum-type slag discharge drum is equipped with an inverted cone structure at both ends, and the contact surface adopts a spoke type to facilitate the removal of bulk materials. The spoke working surface is coated with polyurethane elastomer wear-resistant material through a special process to facilitate Improves wear resistance and cleaning effect, completely protects the roller and tape, and the contact surface adopts a drum-shaped structure, which can correct deviations.​

CONTACT US Conveyor Slag Discharge Pulley
  • Conveyor Slag Discharge Pulley
  • Conveyor Slag Discharge Pulley
  • Conveyor Slag Discharge Pulley

Specifications

Performance features:

◎ Good cleaning effect: The slag discharge roller is used as a tail roller or tensioning roller, and has a good cleaning and removal effect on the materials on the conveyor belt;

◎ Good sealing: the slag discharge drum rotates around the end bearing seat, and the bearing seat seal design structure ensures the good operation of the drum;

◎ Good strength: the thickness of the ribs of the slag discharge roller is 12-15mm, the contact wing with the conveyor belt is 12-20mm, and the width of the single wing is 80mm;

◎ Excellent material: The wing plates can be made of polyurethane elastomer composite wing plates to better protect the conveyor belt;

◎ Wide adaptability: It can operate in harsh environments, including wet and dry conditions, and flame retardant products can be provided for underground use;

◎ Serialized products: The drum diameter, effective length and other dimensions can be customized to meet any specifications with a bandwidth of 500 to 2400mm.

Application: Redirecting drums and counterweight drums of bucket wheel reclaimers in coal mines, steel raw material plants, dock stockpiling yards, power plants and coal yards

PREV: Ceramic Lagging Conveyor Pulley
NEXT:No next article

Recommended Products

KEEP IN TOUCH

SUBMIT
About Us
Jiangyin Huadong Machinery Co., Ltd.
Jiangyin Huadong Machinery Co., Ltd.
Jiangyin Huadong Machinery Co., Ltd is a professional Conveyor Slag Discharge Pulley manufacturers and Conveyor Slag Discharge Pulley company in China, Located in the national high-tech zone in Jiangyin city, Jiangsu province, which was founded in June, 2000 and is a private share company specializing in the R&D and manufacture of conveying machinery equipment. We are a high-tech enterprise and a key enterprise in the same industry of China.
Our company focuses on the product R&D and investment, and with the great support from the government, has founded its research center of high lift conveyor engineering technology, and successively developed an extensive technical exchange and cooperation with many universities and famous organizations such as, Taiyuan University of Science and Technology, Northeastern University, Beijing Iron & Steel Design & Research Institute, Bejing Hoisting & Conveying Machinery Research Institute, German Contitch Company, Britain SBS Company, German KoCH Company etc.; and has successively obtained 22 national patents in the product R&D.
Certificate Of Honor
  • ISO9001 Certificates
  • ISO14001 Certificate
  • ISO45001 Certificate
  • Patent Certificate
  • Patent Certificate
  • Patent Certificate
  • SGS Certificates
  • SGS Certificates
  • SGS Certificates
  • SGS Certificates
News
Belt Conveyor Pulley Industry knowledge

Main structural features of Conveyor Slag Discharge Pulley
Reverse conical structure:
Design: The roller has reverse conical shapes at both ends, which helps to reduce the retention of materials on the roller surface.
Impact: This design promotes the flow of materials, reduces blockage and improves cleaning efficiency.
Spoke contact surface:
Design: The contact surface adopts a spoke design to increase the contact area with the conveyor belt.
Impact: Enhances the ability to grab materials, helps to remove attachments more effectively and prevent sliding.
Wear-resistant coating:
Material: Polyurethane elastomer coating is used to provide good wear resistance.
Impact: Improves the wear resistance of the roller, protects the roller and conveyor belt, extends the service life of the equipment and reduces the replacement frequency.
Seal design:
Features: The bearing part adopts a sealed structure to prevent dust and moisture from intrusion.
Impact: Keep the roller in normal operation, reduce failure rate and reduce maintenance requirements.
Strength and thickness:
Parameters: Rib thickness 12-15mm, contact wing thickness 12-20mm.
Impact: Enhanced roller strength and stability, able to withstand high loads and impacts, ensuring safe operation.

Performance Impact
Cleaning Efficiency:
The combination of reverse taper and spoke design effectively removes materials from the conveyor belt, reduces the risk of sliding and accumulation, and improves work efficiency.
Wear resistance and service life:
The wear-resistant coating and sturdy structural design improve wear resistance, extend service life, reduce replacement frequency and related costs.
Adaptability and Reliability:
Good sealing performance enables the slag discharge roller to work normally under various environmental conditions, enhances the reliability of the equipment, and adapts to harsh environments such as wet and dry.
Maintenance Requirements:
The sturdy design and good sealing performance reduce maintenance requirements, reduce operating and maintenance costs, and make the overall operation more efficient.
Operation Stability:
Due to the rationality of the design, the Conveyor Slag Discharge Pulley can effectively control the movement trajectory of the material, maintain the stable operation of the conveyor belt, and reduce deviation.
