Primary Conveyor Belt Cleaner

As the 1st stage in a multi-stage cleaning system, the primary cleaner removes more of the material attached to the belt, leaving only a thin layer of sticky powder.

The appropriate pressure of the blade on the belt enables the cleaner to peel off the sticky material from the belt at a suitable fixed angle. Using higher pressure at this angle will cause damage to the belt, belt buckle and cleaner itself.

The primary cleaner is usually installed on the surface of the head drum, below the material flow. The construction and installation of the cleaner should avoid affecting the transportation of materials and prevent the accumulation of materials.

CONTACT US Primary Conveyor Belt Cleaner
  • Primary Conveyor Belt Cleaner

Specifications

Performance features:

• PV, HD, HD, MAX, XHD series

• For different size head wheel diameters

• Different blades for different materials

• Excellent cleaning effect and durability

Application: Redirecting drums and counterweight drums of bucket wheel reclaimers in coal mines, steel raw material plants, dock stockpiling yards, power plants and coal yards

PREV: Conveyor Belt Space Precleaner
NEXT:Secondary Conveyor Belt Cleaner

Recommended Products

KEEP IN TOUCH

SUBMIT
About Us
Jiangyin Huadong Machinery Co., Ltd.
Jiangyin Huadong Machinery Co., Ltd.
Jiangyin Huadong Machinery Co., Ltd is a professional Primary Conveyor Belt Cleaner manufacturers and Primary Conveyor Belt Cleaner company in China, Located in the national high-tech zone in Jiangyin city, Jiangsu province, which was founded in June, 2000 and is a private share company specializing in the R&D and manufacture of conveying machinery equipment. We are a high-tech enterprise and a key enterprise in the same industry of China.
Our company focuses on the product R&D and investment, and with the great support from the government, has founded its research center of high lift conveyor engineering technology, and successively developed an extensive technical exchange and cooperation with many universities and famous organizations such as, Taiyuan University of Science and Technology, Northeastern University, Beijing Iron & Steel Design & Research Institute, Bejing Hoisting & Conveying Machinery Research Institute, German Contitch Company, Britain SBS Company, German KoCH Company etc.; and has successively obtained 22 national patents in the product R&D.
Certificate Of Honor
  • ISO9001 Certificates
  • ISO14001 Certificate
  • ISO45001 Certificate
  • Patent Certificate
  • Patent Certificate
  • Patent Certificate
  • SGS Certificates
  • SGS Certificates
  • SGS Certificates
  • SGS Certificates
News
Conveyor Belt Cleaner Industry knowledge

When installing the Primary Conveyor Belt Cleaner, the following key factors need to be considered to ensure its effectiveness and safety:
Location selection:
The main cleaner is usually installed on the surface of the head drum, and it is necessary to ensure that it is located below the material flow so that it can effectively remove the material adhering to the conveyor belt. The installation position should avoid affecting the transportation and flow of materials, and ensure that the blade of the cleaner does not interfere with the normal material unloading.
Angle adjustment:
The angle between the blade and the conveyor belt needs to be adjusted to the optimal position to ensure that the adhering material can be peeled off with appropriate pressure while avoiding damage to the conveyor belt and the cleaner itself. The appropriate angle can improve cleaning efficiency and reduce blade wear.
Blade pressure:
The blade pressure needs to be adjusted according to the material and thickness of the conveyor belt to ensure the cleaning effect while avoiding damage caused by excessive pressure. The appropriate pressure can ensure that the blade effectively peels the material without causing excessive wear on the conveyor belt.
Fixation method:
The fixing method of the cleaner should choose a stable and reliable installation method to ensure that it will not loosen or shift during operation. It is necessary to ensure that the fixing structure can withstand the vibration and impact generated by the cleaner during operation.
Material characteristics: Consider the characteristics of the conveyed material (such as moisture, particle size, viscosity, etc.) to select the appropriate blade material and design to ensure cleaning effect and durability. Different materials may require different cleaning strategies and equipment configurations. Safety: Ensure that safety measures are in place during installation to avoid harm to operators during installation and maintenance. Check the space around the cleaner to ensure that there are no obstacles and potential hazards. Maintenance convenience: Consider the convenience of later maintenance and blade replacement during installation, and choose a location that is easy to access and operate. The design should allow for quick disassembly and replacement to reduce downtime.
